Description
Tokban 300B Vacuum Tube Amplifier 8w*2 High Power DIY Kit Sweet Voice Bluetooth 5.0 Vu Meter 2-channel HIFI Amplifier Audio has multiple configurations.
Please carefully choose you input voltage. US=110V
- Package: Yes
- Channels: 2 (2.0)
- Model Number: 300B
- Maximum Power Per Channel: 8W
- Brand Name: TOKBAN
- Origin: Mainland China
- Certification: none
- Product type: Power amplifier, amplifier audio
- Amplifier type: Tube amplifier, HIFI amplifier,2-channel amplifier, 300B amplifier, single-ended amplifier
- Function: VU meter, volume adjustment
- Bluetooth: Bluetooth 5.0
- Product features: vocals, musical instruments sound sweet, delicate
- Output power: 8w+8w
- Vacuum tube: 6SN7,300BG,274B
- Output impedance: 4ohms 8ohms
- Size: 370*290*220mm
- Weight: 21kg
Tokban 300B Vacuum Tube Amplifier 8w*2 High Power DIY Kit Sweet Voice Bluetooth 5.0 Vu Meter 2-channel HIFI Amplifier Audio
Note
1:You can choose the kit without vacuum tube, if you need, please contact me.
2: The package includes circuit diagram and wiring diagram, please contact me if you have any technical questions.
3: BT=Bluetooth 5.0 in the option.
1:You can choose the kit without vacuum tube, if you need, please contact me.
2: The package includes circuit diagram and wiring diagram, please contact me if you have any technical questions.
3: BT=Bluetooth 5.0 in the option.
300B Sound Description:
1: vocals, violins, light music and other playback is quite sweet, while the bottom of the sound has a certain thickness, high-frequency transparent and delicate, low-frequency is not very exaggerated, the strength is still possible.
1: vocals, violins, light music and other playback is quite sweet, while the bottom of the sound has a certain thickness, high-frequency transparent and delicate, low-frequency is not very exaggerated, the strength is still possible.
2: 300B has a unique sound field, some people say called overtones rich, the pair of amplifiers sound like a little reverb, the sound field is larger, a good sense of stereo.
3: Three frequency articulation natural, loose sound. Personally, I think the 300B sound coloration is larger, listen to what is with a little sweet, but very pleasing to the ear.
4: The details of the high frequency is very good, the midrange is prominent, the low frequency is good. In short, the first choice for vocals, worthy of the king of the vacuum tube 300B!
Product description:
1: This machine uses the amplifier industry recognized classic 6SN7 push 300B circuit, practice has proved that this circuit gain is large enough to push the voltage enough, low distortion, superior performance.
1: This machine uses the amplifier industry recognized classic 6SN7 push 300B circuit, practice has proved that this circuit gain is large enough to push the voltage enough, low distortion, superior performance.
2: 114×70 large power transformer (350W, the same kind of max), 96×45 large output transformer (new stock Z11 0.35 core, 4 + 3 fever winding, the same kind of max)!
Parameters:
Power transformer: 114 * 70 350W, new special piece * 1 (300B kit in the max)
Output transformer: 96 * 45 20W feverish 4 + 3 winding, new inventory of imported new Nippon Iron 0.35 Z11 piece *2 (300B kit in the max)
Choke: 57 * 25 4H new special piece *2
Vacuum tube: 6SN7 / 300B-G*2 / 274B*1
Output power: 8W+8W
Frequency response: 18hz-25khz
Output impedance: 4 and 8 ohms
SNR:89db
Input sensitivity:500mv-1000mv
Input impedance:100kΩ
Harmonic distortion:1%(1khz)
Size:370mm(L)*290mm(D)*220(H)
Weight: about 21KG
Power transformer: 114 * 70 350W, new special piece * 1 (300B kit in the max)
Output transformer: 96 * 45 20W feverish 4 + 3 winding, new inventory of imported new Nippon Iron 0.35 Z11 piece *2 (300B kit in the max)
Choke: 57 * 25 4H new special piece *2
Vacuum tube: 6SN7 / 300B-G*2 / 274B*1
Output power: 8W+8W
Frequency response: 18hz-25khz
Output impedance: 4 and 8 ohms
SNR:89db
Input sensitivity:500mv-1000mv
Input impedance:100kΩ
Harmonic distortion:1%(1khz)
Size:370mm(L)*290mm(D)*220(H)
Weight: about 21KG
