Description

AIYIMA 300B Drive 845 Single ended Class A Amplifier 22W per Channel Pure manual Soldered HIFI is meticulously laid out with premium components.

Product Name: 300B Push 845 Single End A-class

Product Material: Red Pear Wood Frame + Aluminum Plate

Process treatment: Aluminum plate oxidation sanding

Product size: 545 * 420 * 240mm

Weight: Chassis 9 2kg, whole machine 48kg

4 aluminum plates: top 8mm, bottom 4mm, front 5mm, back 3m

Transformers: 1 power transformer, 2 output transformers, 1 filament transformer, 2 inductors

Vacuum tubes: LINLAI 845TA * 2, LINLAI 300B * 2, Xiwannian 6SN7 * 2, SHUGUANG 5AR4 * 2

1. Wooden chassis: Merge mahogany chassis (Zambia minibus flower) 545 * 420 * 100 with aluminum plate: upper 8mm, lower 4mm, front 5mm, back 3mm.

2. Header: Square large header N73 with driver board.

3 Audio output transformer: 114 * 70 0.23mm Kawasaki Z9 top grade steel sheet with stretched cowhide enclosure, Yida oxygen free copper enameled wire, DuPont insulation, withstand voltage greater than 4KV.

4. High voltage power transformer: 114 * 80 0.35mm Kawasaki Z11 steel sheet with stretch cowhide sealing, Yida oxygen free copper enameled wire, DuPont insulation, withstand voltage greater than 4KV

5 medium voltage filament transformer: 114 * 70 0 35mm Kawasaki Z11 steel sheet stretch cowhide sealing, Yida oxygen free copper enameled wire, DuPont insulation, withstand voltage greater than 4KV

6 High Voltage Inductance Choke Coil: 86 * 45 0.35mm Kawasaki Z11 steel sheet with stretched cowhide enclosure, Yida oxygen free copper enameled wire, DuPont insulation, withstand voltage greater than 4KV.

7 Medium Voltage Inductance Choke Coil: 76 * 40 0.35mm Kawasaki Z11 Steel Sheet Stretch Bull Cover Encapsulation, Yida Oxygen Free Copper Enamel Wire, DuPont Insulation, Withstand Voltage greater than 4KV

8 845 electronic tube socket: gold-plated

9 Other sockets: EIZZ 4-pin+8-pin

10 RCA Input Selection Kit: Three sets of RCA inputs, band switch, circuit board and other kits, including 6 RCA gold-plated terminals

11 horn terminals: carbon fiber coated with rhodium

12 volume potentiometer: ALPS 27 blue shell

13 all aluminum knob: 38mm

14 all aluminum foot pads: 45mm

15 switch/input: socket button switch, with fuse socket

16 capacitors: a complete set of ruby, BC, Soviet oil immersed coupling capacitors

17 resistors: a set of Panasonic and DALE imported resistors

18. Other accessories inside the machine, such as shed boards and internal wiring
